CE 1200Pcs/Min Full Servo Sanitary Pad Making Machine One Stop Solution Factory

Name: CE 1200PcsMin Full Servo Sanitary Pad Making Machine One Stop Solution Factory
Brand: WOMENG
Price: 350000 USD

Quality CE 1200Pcs/Min Full Servo Sanitary Pad Making Machine One Stop Solution Factory for sale

Brand Name : WOMENG

Model Number : WM-NSP01

Certification : CE,ISO9001,SGS

Place of Origin : Quanzhou City,China

MOQ : 1piece

Price : $350000~$500000

Payment Terms : L/C,T/T

Supply Ability : 12sets/year

Delivery Time : 90-120 days

Packaging Details : Seaworthy Wooden Box

Operator : 2-3 persons

Hs Code : 84418090

After-sale Service : Engineers Service Oversea/Video Technical Support

Warranty : 12Months

Machinery Test Report : Provided

Regional Customization : Support

Contact Now

CE 1200Pcs/Min Full Servo Sanitary Pad Making Machine One Stop Solution Factory

Key Specifications

Production Speed	800-1200 pieces per minute
Product Size	240mm,290mm,320mm,420mm(Customized according to customer requirement)
Production Yield Rate	≥98%
Weight	About 50 tons
Machine Size	2543m(LWH)
Safety System	It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
Raw Material	Fluff pulp, SAP, non-woven fabric, PE film
Control System	PLC control system(Mitsubishi),HMI Operating on the LED touch
Drive system	Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
Power	240V,50Hz,3 Phase Five Wire
Optional Functions	1. Camera monitoring system (control online size checking, location inspecting, missing inspecting, stain spot scanning and so on.) 2. Material roll auto unwinding servo control 3. Material roll auto unwinding converter control 4. Automatic Packing machine 5. Full-servo control stacker (auto bagging machine) 6. Automatic bagging sealing machine

Technical features:

* Compact design, easy operation & maintenance
* Modular design, for future upgrading
* Low consumption, high efficiency
* Servo or frequency inverter transmission
* Touch screen for man-machine conversation
* Auto record and calculation of process data
* Main raw material auto splicing at zero speed
* Inverter or servo unwinding with tension control
* Web guiding controller
* Sensor quality control systems
* Material broken and lost inspection, auto machine stops and defective products auto rejection
* Easy size changing and manufacture

Sanitary Pad: Detailed Structure & Material Parameters Table

Core Structure	Sub-Structure	Main Materials	Key Features
Surface Layer	Skin-Friendly Layer	Combed Cotton,Bamboo Fiber	Soft, skin-friendly, breathable
	Breathable Layer	Microporous Non-Woven Fabric	Moisture-wicking, reduces stuffiness
Distribution Layer	Rapid Penetration Layer	High-Puff Non-Woven Fabric	Fast liquid absorption, no local accumulation
	Despersion Layer	Patterned Non-Woven Fabric	Even liquid distribution
Absorbent Core	SAP Locking Layer	Super Absorbent Polymer (SAP)	High water absorption, anti-reverse osmosis
	Support Layer	Fluff Pulp, Hollow Fiber	High water absorption, anti-reverse osmosis
Leak-Proof Bottom	PE Breathable Film	Polyethylene Breathable Film	Waterproof, breathable
	Anti-Slip Adhesive	Medical-Grade Adhesive	Secure fit, no displacement
Wings	Fixing Wings	Rigid Non-Woven Fabric	Anti-side shift
	Leak-Proof Edges	Elastic Non-Woven Fabric	Enhanced side leakage protection

Machine Panoramic Image

Adapt to low-skilled labor and reduce the difficulty of human resource management

Minimalist operation with no threshold:

The core process is equipped with "one-click start" and "automatic calibration" functions. Common problems such as fabric deviation and uneven glue amount can be automatically corrected without the need for manual adjustment by workers. With a multilingual graphic manual and hands-on teaching videos, workers without industrial operation experience can start working after one week of training, significantly reducing recruitment and training costs in emerging markets.

Low labor intensity and stable team: Automated completion of heavy tasks such as raw material transportation, core laying, cutting and pressing, workers only need to be responsible for simple tasks like raw material replenishment and finished product collection, reducing repetitive high-intensity labor. The workshop layout has been optimized, with workers having a shorter walking distance and a higher working comfort level, effectively reducing the employee turnover rate in areas with high labor mobility.

Strengthen the flexibility of raw material adaptation to cope with fluctuations in the supply chain

Compatible with multiple quality raw materials:

By fine-tuning the servo parameters (conveying speed, pressing pressure), it can be compatible with non-woven fabrics of different grammages (deviation ±5g/㎡) and water-absorbing resins of different water absorption ratios (deviation ±10%), and can cope with fluctuations in raw material quality without equipment modification. Even in areas with tight raw material supply, alternative raw materials can be flexibly selected to avoid production disruptions.

Support low-cost raw material solutions: Provide targeted raw material substitution guidance. For instance, in the economy market, it is recommended to use high cost-performance chemical fiber non-woven fabric to replace pure cotton surface layer, or to use mixed water-absorbing resin to replace pure polymer resin. The production line can be seamlessly adapted to help buyers reduce procurement costs and enhance the price competitiveness of their products.

sanitary pad making machine for Latvia,sanitary pad machine for Lithuania,sanitary napkin making machine for Belarus,sanitary pad production line for Russia,sanitary pad manufacturing machine for Moldova
